主要用途与筒介：Purpose and introduction

滤油机应使用于对30-500ML产品玻璃窗瓶、橡胶瓶的罐装封好。选用经济往来交往式连杆进行罐装，电磁波振荡器送盖，能够轧盖(金属材料式)或旋盖(橡胶盖)封好，能够和前后轮的出产的生产工序仪器联结结构出产线，凡此种种能够鉴别百级层流罩。This machine is suitable for the filling and sealing of 30-500ml series glass bottles and plastic bottles. The reciprocating between piston filling, electromagnetic oscillation send cover, cover (metal) can be rolled or screw cap (plastic cap) sealing. Can produce and the produce of the process equipment before and after connecting line. In addition, the laminar flow hood is available for selection.

基本特征：characteristic

装量明确，杜尽漏滴。缺瓶不装灌。 变频式可控硅调压。 拒绝显示信息记数副作用。 整个机器均按GMP想要设计方案。The filling amount is accurate, as Du drip. Lack of bottle does not fill. Frequency control of motor speed. Active display count. The machine according to the GMP request design.

系统基本参数/technical parameters：

型号 model	NQGX30-500
采用尺寸Cutting dimension	30-500ml
盛产程度Production capacity	80-200瓶/分（罐/多分钟）80-200 bottles/min (cans/min)
灌装设备高精度 Filling accuracy	≤±1%
电源适配器 Power	380V/50Hz
旋（轧）盖率Spin (rolling) cover rate	≥99%
功率power	3.0 kw
自动化净重量 Machine weight	1500 kg
外形尺寸 boundary dimension	3000*1100*1700mm
